Maximum technology, minimum space requirements! To complement the existing Metrix® oscilloscope ranges, the new OXi 6204 model is designed for the laboratory and education markets as a replacement for the mixed differential oscilloscopes. It offers a compact design, simple use and practical functions at a competitive price. It is simultaneously an oscilloscope, multimeter, logger and FFT / harmonic analyser, meeting the needs of engineers, lab technicians, technical staff, teachers and electrical and electronic equipment manufacturers. There are many potential applications as the OXi 6204 is equipped with 4 channels isolated from one another and in relation to the earth, which means it can be used with up to 4 independent integrated differential probes. Technical performance The OXi 6204 is equipped with a bandwidth of 200 MHz. It offers fast sampling with high resolution thanks to its 12-bit / 2.5 GS/s converter, a 100 GS/s sampling rate on periodic signals and 1 ns transient capture, thus avoiding undersampling. The graphical "Winzoom" function takes full advantage of the vertical resolution of the 12-bit converter, four times greater than that of a traditional 8-bit converter, ensuring unrivalled accuracy. This feature also provides an improved dynamic range of 60 dB, optimizing accuracy for frequency and amplitude measurements. The OXi 6204 is equipped with 4 isolated 600 V CAT II measurement channels and displays up to 4 curves on screen. In oscilloscope mode, you can directly view the 20 automatic measurements by simply pressing the dedicated button. The 4 TRMS 8,000-count digital multimeters included in the OXi 6204 can be used for classic voltage, resistance, continuity, capacitance and frequency measurements, diode tests and Pt100 temperature measurements, as well as single-phase and even three-phase power measurements on the 200 kHz bandwidth. Time/date-stamped graphical recording is performed on all the active channels over periods ranging from 5 minutes to 1 month. Calculated on 2,500 counts, the FFT analysis can be adjusted automatically by pressing the Autoset key. Analysis of the even and odd harmonics is performed up to the 61st order to comply with the requirements of the EN 50160 standard (THD on 50 orders minimum), with a fundamental frequency between 40 and 450 Hz. Simple implementation Compact and stable, with a built-in handle and storage compartment, the OXi 6204 is easy to move around. For greater safety, the terminal strip is equipped with reinforced-plastic BNC connections which are isolated from one another and in relation to the earth. A reminder of the channel colours is provided on each connection. The colour TFT graphical screen is touch-sensitive so you can use its magnetized stylus to adjust your settings directly on screen (position of the traces, trigger level, cursors or zoom). The 32 keys for direct access to the various modes and parameters and universal "Windows-like" menus available in 5 languages make it even simpler to use. Communication expert The OXi 6204 is effective for both laboratory and remote use and can adapt to new working methods thanks to its Ethernet interface (10 MB transfers) and SCOPENET web server. It also allows printing on network printers; remote management and file exchange on FTP server. Measurements made remotely with the OXi 6204 are now accessible on tablets and AndroidTM smartphones. Via the WiFi connection, the SCOPENET application also offers real-time display of the measurements whatever your location.

vPad-RF, the smallest full-featured Electrosurgical Unit (ESU) Analyzer on the market, is designed to test all makes and models of ESUs including continuous and pulsed-wave systems. One of the unique features of vPad-RF is that it includes a built-in High Frequency Digital Oscilloscope and Spectrum Analyzer, allowing users to investigate complex waveforms using only one piece of test equipment. Ron Evans, President of Datrend Systems stated, “By utilizing state-of-the-art Digital Signal Processing techniques along with the computing power available on the Vision Pad Platform, we are able to offer functionality that is unique in our marketplace. Building the product on the vPad platform has also allowed us to provide the user with enhanced data recording, reporting and most importantly, integrated maintenance checklists which provide users step-by-step instructions for carrying out complex preventative maintenance procedures. As with our other products built on this platform, transferring test records to external data repositories can be done via Bluetooth, Wifi or USB”. For more information on this and Datrend’s other innovative products visit the company’s website www.datrend.com or contact them directly at 604-291-7747 About Datrend Systems Inc. Datrend Systems Inc. is a Canadian based biomedical engineering company focused on developing and manufacturing leading edge biomedical test instrumentation for hospitals, clinics and medical equipment manufacturers. Since our launch in 1991, we have expanded to serve global markets with innovative products
